3M™ Cold Shrink QS4 Integrated Splice Kits 35-TS Series

10 Products

1 of 1

Hover to zoom

Inline splice for joining tape shield, wire shield, UniShield® and LC power cables
Special-electrode design reduces electrical stress at critical cable and splice interface
Designed for feeder and distribution circuits, size transition splicing, direct-burial installations and submerged locations
Rated for 35 kV cables

View all details

For industrial/occupational use only. Not for consumer sale or use.

Conductor Sizes (Imperial)

Conductor_Sizes

10 Products Available

Available options:

Conductor Sizes (Imperial)

Specifications

Attribute Name	Value
Brand	3M™
Cable Shielding	Jacketed Concentric Neutral (JCN), Longitudinally Corrugated (LC), Tape Shield, UniShield®, Wire Shield
Conductor Material	Aluminum, Copper
Conductor Sizes (Imperial)	1/0 AWG, 1000 kcmil, 2/0 AWG, 250 kcmil, 3/0 AWG, 300 kcmil, 350 kcmil, 4/0 AWG, 400 kcmil, 500 kcmil, 600 kcmil, 700 kcmil, 750 kcmil, 800 kcmil, 900 kcmil
Insulation Level	1.33, 100%, 133%
Insulation Outer Diameter (Imperial)	1.07 in, 1.08 in, 1.09 in, 1.1 in, 1.11 in, 1.12 in, 1.13 in, 1.14 in, 1.15 in, 1.16 in, 1.17 in, 1.18 in, 1.19 in, 1.2 in, 1.21 in, 1.22 in, 1.23 in, 1.24 in, 1.25 in, 1.26 in, 1.27 in, 1.28 in, 1.29 in, 1.3 in, 1.31 in, 1.32 in, 1.33 in, 1.34 in, 1.35 in, 1.36 in, 1.37 in, 1.38 in, 1.39 in, 1.4 in, 1.41 in, 1.42 in, 1.43 in, 1.44 in, 1.45 in, 1.46 in, 1.47 in, 1.48 in, 1.49 in, 1.5 in, 1.51 in, 1.52 in, 1.53 in, 1.54 in, 1.55 in, 1.56 in, 1.57 in, 1.58 in, 1.59 in, 1.6 in, 1.61 in, 1.62 in, 1.63 in, 1.64 in, 1.65 in, 1.66 in, 1.67 in, 1.68 in, 1.69 in, 1.7 in, 1.71 in, 1.72 in, 1.73 in, 1.74 in, 1.75 in, 1.76 in, 1.77 in, 1.78 in, 1.79 in, 1.8 in, 1.81 in, 1.82 in, 1.83 in, 1.84 in, 1.85 in, 1.86 in, 1.87 in, 1.88 in, 1.89 in, 1.9 in, 1.91 in, 1.92 in, 1.93 in, 1.94 in, 1.95 in, 1.96 in, 1.97 in, 1.98 in, 1.99 in, 2 in, 2.01 in, 2.02 in, 2.03 in, 2.04 in, 2.05 in, 2.06 in, 2.07 in
Number of Conductors	1
Splice Type	Cold Shrink
Voltage	35 kV

Details

Inline splice for joining tape shield, wire shield, UniShield® and LC power cables
Special-electrode design reduces electrical stress at critical cable and splice interface
Designed for feeder and distribution circuits, size transition splicing, direct-burial installations and submerged locations
Rated for 35 kV cables
Withstands a temperature range of 221 to 284 °F (105 to 140 °C)

The new 3M™ Cold Shrink QS4 Integrated Splice Kit is a premier offering that utilizes our field-proven 3M™ Cold Shrink QS-III Splice Body with additional features that make installation quick and easy. This exciting product integrates all of the layers of a shielded power cable splice into one compact joint.

With this splice, 3M is introducing our easy-to-use yellow core and rejacketing tube. We incorporated our smooth-edged shield sock (non-fraying ends) with optional customizable ground braid. The Tape Shielded (TS) inline splice kits below are designed for joining Tape Shield, Wire Shield, UniShield® and Longitudinally Corrugated (LC) power cables. The splice includes a separate 7 AWG U-shaped ground braid that can be attached to the shield with a constant force spring for external grounding. Note: Cable sizes shown below are for standard insulation thickness. Final determining factor is cable insulation O.D.

Resources

Brochures

3M™ Cold Shrink QS4 Integrated Splice (PDF, 845.5KB)

Data Sheets

Instructions

3M™ Cold Shrink QS4 Integrated Splice Kit QS4-35TS-1/0-350 (PDF, 1.8MB)

Regulatory Material

EMD Shelf Life Statement (PDF, 90.3KB)

Safety Data Sheets

For industrial/occupational use only. Not for consumer sale or use.

3M industrial and occupational products are intended, labeled, and packaged for sale to trained industrial and occupational customers for workplace use. Unless specifically stated otherwise on the applicable product packaging or literature, these products are not intended, labeled, or packaged for sale to or use by consumers (e.g., for home, personal, primary or secondary school, recreational/sporting, or other uses not described in the applicable product packaging or literature), and must be selected and used in compliance with applicable health and safety regulations and standards (e.g., U.S. OSHA, ANSI), as well as all product literature, user instructions, warnings, and other limitations, and the user must take any action required under any recall, field action, or other product use notice. Misuse of 3M industrial and occupational products may result in injury, sickness, death, or property damage. For help with product selection and use, consult your on-site safety professional, industrial hygienist, or other subject matter expert.
