3M™ Acrylic Foam Tape 4225, White, 3.18 mm

  • 3M Product Number 4225
  • 3M ID B40065708

Attaches exterior parts to contours and complex geometries for a long-lasting bond

3.18 mm thick viscoelastic foam core handles higher loads

Acrylic adhesive delivers high initial tack, rapid build and excellent final adhesion, as well as high peel and shear strength

View more details

Details

Highlights
  • Attaches exterior parts to contours and complex geometries for a long-lasting bond
  • 3.18 mm thick viscoelastic foam core handles higher loads
  • Acrylic adhesive delivers high initial tack, rapid build and excellent final adhesion, as well as high peel and shear strength
  • Great for rocker panels, body side moldings, roof ditch moldings, claddings and appliques
  • Red, 3M-branded liner helps ensure easy one-piece release for efficient application
  • For a full range of automotive substrates, providing flexibility and stress handling
  • Proprietary branded liner makes this tape easy to identify and difficult to imitate

3M™ Acrylic Foam Tape 4225, White, 3.18 mm is an automotive attachment tape that brings good adhesion, increased stress handling and flexibility to attaching exterior parts to contours and complex geometries in automotive applications. This white tape, with its 3.18 mm thick viscoelastic foam core, provides excellent wet-out to surface contours, helping ensure a secure bond. It handles higher loads and provides stress relaxation for a strong bond.

Silver window trim attached to a red car
Superior adhesion performance and high flexibility
Designed for Attaching Exterior Parts Even to Contours and Complex Geometries
Developed specifically for a full range of automotive substrates, 3M™ Acrylic Foam Tape 4225 is ideal for attaching parts such as side body moldings, rocker panel moldings and other parts requiring a combination of flexibility and stress handling. This tape features a 3.18 mm viscoelastic acrylic foam core which provides excellent conformability and wet-out, ideal for consistent attachment around contours. An acrylic adhesive applied to both sides delivers high initial tack, rapid build and excellent final adhesion as well as high shear and peel strength.

Thick Foam Core Handles Higher Loads
The thick, 3.18 mm viscoelastic foam core on 3M™ Acrylic Foam Tape 4225 conforms well even to complex geometries. It is engineered for stress relaxation when exposed to high stress loads, and maintains bond-line aesthetics under normal stress loads. The white color of this OEM approved tape helps create sharp bond-lines. A red, 3M branded liner provides easy one-piece release for efficient application.

Confidence in Your Purchase
The 3M branded liner features a subtle 3M logo marking to provide evidence to the customer that they are receiving the 3M quality they expect from their purchase. The liner makes our tapes easy to identify and difficult to imitate. Proprietary branding technology is designed to help identification of 3M™ Acrylic Foam Tape.

Recommended Applications
  • Body side moldings
  • Roof ditch moldings
  • Claddings
  • Appliques

Better Science for Better Adhesion from 3M
Since 1925 when one of our lab assistants invented masking tape, 3M has been applying science to life — developing adhesive products and technologies that help entire industries and individual businesses worldwide. The work that began with a single 3M engineer now spans decades and generations — and all of it goes into each of our products developed for automotive OEM, like 3M™ Acrylic Foam Tape 4225.

See more Attachment tapes

Typical properties
