- Suitable for use in challenging environments, such as a factory production floor
- Robust ribbon style contact for reliable, repetitive plugging
- Body tabs provide lateral support to solder joints and help enable shield grounding
- Upright orientation conserves PCB real estate
Specifications
|
Attribute Name
|
Value
|
|---|---|
|
Brand
|
3M™
|
|
Connector Style
|
Plug
|
|
Contact Base Material
|
Copper Alloy
|
|
Flammability
|
UL 94V-0
|
|
Mounting Type
|
Boardmount
|
|
Tech Sheet Number
|
TS-2294, TS-2295, TS-2397
|
Details
- Suitable for use in challenging environments, such as a factory production floor
- Robust ribbon style contact for reliable, repetitive plugging
- Body tabs provide lateral support to solder joints and help enable shield grounding
- Upright orientation conserves PCB real estate
- 360(deg) shielding for excellent EMI protection
- Six contacts can carry signal or power (up to one amp per pin)
- Polarized to provide proper cable insertion
- Latching wiremount connector for mated vibration resistance
- For more information, refer to Customer Drawing 78-5100-2397-7
- For more information, refer to Data Sheet TS2294 (TS-2294)
Boardmount Straight (Vertical) Through-hole Plug (Male) for IEEE 1394
Resources
3D Models
- 3E106-2230KV, 3D IGES, rev. 01 (ZIP, 871.6KB)
- 3E106-2220KV, 3D IGES, rev. 01 (ZIP, 850.1KB)
- 3E106-2220KV, 3D Parasolid, rev. 01 (ZIP, 1.1MB)
- 3E106-2220KV, 3D Step, rev. 01 (ZIP, 234.6KB)
- 3E106-0220KV, 3D IGES, rev. 01 (ZIP, 1.1MB)
- 3E106-2230KV, 3D Parasolid, rev. 01 (ZIP, 1.2MB)
- 3E106-2230KV, 3D Step, rev. 01 (ZIP, 243.7KB)
- 3E106-0220KV, 3D Step, rev. 01 (ZIP, 245.2KB)
- 3E106-0220KV, 3D Parasolid, rev. 01 (ZIP, 1.3MB)
