3M™ Ultra Clear Double Coated Tape UCT-30, Clear, 1200 mm x 200 m, 1 Roll/Case

  • 3M Product Number UCT-30
  • 3M ID 7010532146
  • UPC 06936177906972

1.0 mil (0.030mm) double sided acrylic tape with 90% light transmission and 1.1% haze

Excellent initial tack with good adhesion and shear strength

Produced in a clean room to help keep finished products free of dirt, dust and debris

View more details

Details

Highlights
  • 1.0 mil (0.030mm) double sided acrylic tape with 90% light transmission and 1.1% haze
  • Excellent initial tack with good adhesion and shear strength
  • Produced in a clean room to help keep finished products free of dirt, dust and debris
  • Exceptionally clear polyester (PET) carrier with PET liner on each side for easy die cutting
  • Non-silicone acrylic adhesive leaves no silicone residue

3M™ Ultra Clear Double Coated Tape UCT-30 is an exceptionally clear double-sided tape for display screen assembly that offers 90% light transmission and 1.1% haze. A polyester (PET) carrier and two PET liners provide dimensional stability for die cutting, with a non-silicone acrylic adhesive. This tape is produced on a clean room coater to help keep finished products free of dust and debris.

Clean and Clear Bonding for Light Transmission
3M™ Ultra Clear Double Coated Tape UCT-30 is a double-sided acrylic tape engineered for 90% light transmission and just 1.1% haze, making it ideal for bonding display screens, lenses and backlit graphics. In addition to the exceptionally clear polyester (PET) carrier and adhesive, this tape is produced in a clean room and protected by a liner on each side to help keep your finished products free of dust and debris. The PET carrier and liners also provide dimensional stability for die cutting. Without the liners this tape is 1.0 mils (0.030mm) thick. The non-silicone acrylic adhesive leaves no silicone residue.

Recommended Applications

  • Cell phone lens attachment
  • Tablet screen attachment
  • Backlit graphics attachment
  • Backlit control button bonding
  • Electronics and appliance applications requiring excellent light transmission, high initial tack and easy die cutting

Bringing Better Ideas to the Surface Through Science and Innovation
The 3M Industrial Adhesives and Tapes Division, applies the science of adhesion to deliver innovative solutions that improve the design and manufacturing processes of companies around the world. In the end, 3M technologies help customers like you deliver competitive products to the market faster and more efficiently.



See how 3M™ Ultra Clear Double-Coated Tape UCT-50 brings products to life (PDF, 378.79 Kb)
