3M™ Highland™ Vinyl Insulated Female Disconnect Terminal FDV10-250Q, AWG 12-10, 25/bag, 10 Bags/Case

3M™ Highland™ Vinyl Insulated Female Disconnect Terminal FDV10-250Q, AWG 12-10, 25/bag, 10 Bags/Case

Part Number FDV10-250Q
3M ID 7000133661
UPC 00051128600047

Vinyl-insulated, butted-seam barrel with a funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires

Dents and rolled edges of this female disconnect terminal offer excellent holding force

Allows for quick and easy disconnect of wires

View more details

Frequently viewed resources

Tech Data Sheet (PDF, 26KB)

Where to Buy

Details

Highlights

Vinyl-insulated, butted-seam barrel with a funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
Dents and rolled edges of this female disconnect terminal offer excellent holding force
Allows for quick and easy disconnect of wires

3M™ Highland™ Vinyl Insulated Butted Seam Female Disconnect has dents and rolled edges to offer superior holding force while allowing for quick and easy disconnect. The terminal has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its durable brass construction offers good conductivity and a tin-plated finish resists corrosion.

3M™ Highland™ Vinyl Insulated Butted Seam Female Disconnect attaches to the mating part with a tongue that slips over the male tab. It has a butted-seam barrel that is covered by a funnel-designed, rigid-molded, polyvinyl chloride sleeve. The polyvinyl chloride sleeve serves to guide the wire into position while providing electrical contacts and mechanical stress relief at the point of insulation. The vinyl-sleeve insulation is abrasion-resistant and flared to ensure easy crimping. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.

Typical properties

Details

Barrel Inside Diameter	0.128 Inch
Barrel Length (Imperial)	0.25 Inch
Barrel Length (Metric)	6.35 mm
Barrel Style	Butted
Brands	Scotchlok™
CSA File Number	LR22190
Connection Width (Imperial)	0.25 in
Connection Width (Metric)	6.35 mm
Disconnect Type	Female
Fastener Orientation	Female
Insulation Material	Vinyl
Material	Plastic
Mates with Female Width	0.25 Inch
Mates with Male Tab Width (W')	0.25 Inch
Max. Number of Cores	416
Maximum Conductor Size (Imperial)	10 AWG
Maximum Conductor Size (Metric)	6 mm²
Maximum Insulation Outer Diameter (Imperial)	0.25 in
Maximum Insulation Outer Diameter (Metric)	3.7 mm
Maximum Insulation Outside Diameter	0.145 in
Maximum Recommended Voltage Rating	600 V
Maximum Voltage Rating	600 to 1000 V
Minimum Conductor Size (Imperial)	12 AWG
Minimum Conductor Size (Metric)	4 mm²
Pad Width	0.25 in
Tab Width	0.250
Terminal Style	Standard
Terminal Type	Disconnect
UL File Number	E70512
Units per Case	10.0
Units per bag	25

Dimensions and Classifications

Overall Length (Imperial)	0.95 in
Overall Length (Metric)	24.13 mm
