3M™ Adhesive Transfer Tape 9626

3M Product Number 9626
Products
  • Natural, 2 mil (0.06 mm) adhesive transfer tape on a 60# glassine paper liner
  • Quick stick adhesion and immediate bond
  • Exceptional adhesion properties and bonds well to high and low surface energy plastics
  • Good solvent and moisture resistance
 More...
View all details
For industrial/occupational use only. Not for consumer sale or use.
Overall Length (Imperial)
Overall_Length_Imperial
Overall Width (Imperial)
Overall_Width_Imperial
Products Available
Available options:
 Overall Length (Imperial) and Overall Width (Imperial)
All Options
Close
Specifications
Attribute Name
Value
Adhesive Type
Acrylic
Alternative Sale Availability
6. This item is for industrial use only and there are no VOC restrictions.
Automotive OEM Specification
Ford WSS-M11P62
Brand
3M™
Color Family
Transparent
Industries
Aerospace, Automotive, Converter Solutions, Electronics, General Industrial, Medical, Specialty Vehicle, Transportation, Woodworking
Maximum Operating Temperature (Celsius)
93 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
200 Degree Fahrenheit
Minimum Operating Temperature (Fahrenheit)
-40 Degree Fahrenheit
Overall Length (Imperial)
180 yd, 60 yd
Overall Length (Metric)
164.59 m, 55 m
Overall Width (Imperial)
48 in, 54 in
Overall Width (Metric)
1219.2 mm, 1371.6 mm
Primary Liner
60# Glassine Paper
Primary Liner Color
Tan
Primary Liner Thickness (Imperial)
3.2, 3.2 mil
Primary Liner Thickness (Metric)
0.08 mm
Regulatory Key
AD-00140
Substrate 1
Foam (EPDM - EVA - Neoprene - Nitrile Sponge Blend - Polyurethane, Ester), Foam (Melamine), Foam (Polyimide), Foam (Polyurethane, Ether), Foam (PVC), Glass (Inked Glass - Ceramic), Metal (Aluminum - Powder Coated - Copper - Stainless Steel - Zinc/Galvanized), Plastics/Composites (ABS - Carbon Fiber - Acrylic - Fiberglass - Polycarbonate - Polyester - Polyimide - Polystyrene - Rigid Vinyl), Plastics/Composites (Glass Filled Nylon), Plastics/Composites (Nylon - PEEK - Polyethylene - Polypropylene)
Substrate 2
Foam (EPDM - EVA - Neoprene - Nitrile Sponge Blend - Polyurethane, Ester), Foam (Melamine), Foam (Polyimide), Foam (Polyurethane, Ether), Foam (PVC), Glass (Inked Glass - Ceramic), Metal (Aluminum - Powder Coated - Copper - Stainless Steel - Zinc/Galvanized), Plastics/Composites (ABS - Carbon Fiber - Acrylic - Fiberglass - Polycarbonate - Polyester - Polyimide - Polystyrene - Rigid Vinyl), Plastics/Composites (Glass Filled Nylon), Plastics/Composites (Nylon - PEEK - Polyethylene - Polypropylene)
Units per Case
1 Roll
Details
  • Natural, 2 mil (0.06 mm) adhesive transfer tape on a 60# glassine paper liner
  • Quick stick adhesion and immediate bond
  • Exceptional adhesion properties and bonds well to high and low surface energy plastics
  • Good solvent and moisture resistance
  • Laminating adhesive format provides good conformability to irregular surfaces

3M™ Adhesive Transfer Tape 9626 immediately bonds to high and low surface energy materials. The 60# glassine paper liner provides dimensional stability and improved handling with ease in die cutting and laminating applications.

Exceptional Strength from Thin Bond Lines
Engineered for quick and strong adhesion, 3M™ Adhesive Transfer Tape 9626 offers high bond strength on a variety of materials, including hard-to-stick-to polypropylene and powder-coated paints. Designed with just 2 mil (0.06 mm) of 3M™ Quick Bonding Adhesive 360, it provides exceptional strength with minimal adhesive, delivering a strong, yet light and smooth application and thin bond lines. The tape is resistant to humidity, UV, water, short term temperatures up to 250°F (121°C) and chemicals (including oil, mild acids, and alkalis).

Recommended Applications

  • Plastic housing and component assembly (bezel bonding)
  • Interior decorative trim attachment

The 360 Advantage
3M™ Adhesive Transfer Tape 9626 features 3M™ Quick Bonding Adhesive 360 which provides high bond strength with low odor and little or no oozing. The noted advantages of 360 adhesive are its extremely high peel adhesion and equally high adhesion on both polypropylene and steel substrates. It offers more bond strength with less adhesive as well as quick stick to many low surface energy substrates.

Understanding Adhesive Transfer Tapes
Adhesive transfer tapes (PDF, 29.69 Kb) are rolls of pressure sensitive adhesive pre-applied to a special release liner. For application, the tape is simply pressed, adhesive side down, to a surface and the liner is peeled off. A variety of adhesive properties and liners are available to meet requirements for applications such as nameplate attachment to high and low surface energy plastics, appliance graphic overlays that perform in high temperatures, foam gasketing, web splicing, signs, posters, banners, point-of-purchase displays, and more.


Image of finite element modeling showing stress points on interacting gearwheels
Get Data for Finite Element Analysis

Pressure Sensitive Adhesive properties are frequency and temperature sensitive. 3M has developed Material Data Cards (MDCs) for common 3M PSAs for use with many commercially available FEA software applications. Learn more.

REQUEST A 3M MATERIAL DATA CARD
