3M™ EMI Shielding Fabric Tape CN-3190

3 Products

1 of 1

Hover to zoom

Highly conformable with an acrylic adhesive
Copper nickel-plated shielding provides greater flexibility and good conformability
Suitable for the grounding and EMI shielding of equipment, components and shielded rooms
For prototyping, design and troubleshooting in electrical design

View all details

For industrial/occupational use only. Not for consumer sale or use.

Overall Length (Imperial)

Overall_Length_Imperial

Overall Length (Metric)

Overall_Length_Metric

Overall Width (Imperial)

Overall_Width_Imperial

Overall Width (Metric)

Overall_Width_Metric

3 Products Available

Available options:

Overall Length (Imperial), Overall Length (Metric), Overall Width (Imperial) and Overall Width (Metric)

Specifications

Attribute Name	Value
Adhesive Type	Acrylic
Backing (Carrier) Thickness (Imperial)	3.5 mil, 4.3 mil
Backing (Carrier) Thickness (Metric)	0.089 mm, 0.109 mm
Backing Material	Nickel/Copper-coated Polyester
Brand	3M™
Overall Length (Imperial)	54.5 yd
Overall Length (Metric)	50 m
Overall Width (Imperial)	1 in, 20.6 in, 41.3 in
Overall Width (Metric)	1049 mm, 25.4 mm, 523.24 mm
Size (Imperial)	20.6 in x 54.5 yd
Size (Metric)	1049 mm x 50 m
Specifications Met	RoHS 2011/65/EU
TDS Required	Yes

Details

Highly conformable with an acrylic adhesive
Copper nickel-plated shielding provides greater flexibility and good conformability
Suitable for the grounding and EMI shielding of equipment, components and shielded rooms
For prototyping, design and troubleshooting in electrical design
Removable liner for easy die-cutting and handling
RoHS 2011/65/EU Compliant

3M™ EMI Shielding Fabric Tape CN-3190 is a 4.3 mil thick, acrylic adhesive shielding tape. This tape is suitable for applications such as the grounding and EMI shielding of equipment, components and shielded rooms. It comes on a removable liner for easy die cutting and handling.

3M™ Tape CN-3190 has corrosion resistant, polyester ripstop fabric backing with a conductive, acrylic adhesive that ensures firm adherence. This tape offers copper nickel shielding with good conformability and flexibility. It is suitable for prototyping, designing and troubleshooting in electrical design and test laboratories. The tape is designed for applications that require reliable, point to point electrical contact. RoHS 2011/65/EU Compliant.

Resources

Brochures

Regulatory Material

EMD Shelf Life Statement (PDF, 90.3KB)

Safety Data Sheets

3M™ Shielding PET Rip-stop Fabric Tape CN-3190 (PDF)
