3M™ Thermally Conductive and Heat Spreading Tape 9876-10
- 3M ID 7000008596
- UPC 00051115526503
3M™ Thermally Conductive Interface Tapes
Details
Highlights
- Excellent thermal conductivity on plane direction ( >210-250 W/m-K)
- Excellent flexibility
- Selective thermal spreading path for uniform heat distribution
- Excellent electrical insulation
- High performance acrylic adhesive provides excellent adhesion to Aluminum and SUS
- Easy workability and handling (easy die cut)
3M™ Thermally Conductive and Heat Spreading Tape 9876-10 provides excellent heat spreading performance on plane direction for stimulation of quick heat dissipation with a preferential heat-transfer path between heat-generating components.
Generally, heat spreaders conduct to distribute thermal energy from a heat-generating component to another location where the heat can be removed through a heat dissipation mechanism. Focused on increasing the X-Y direction thermal conductivity to enhance heat spreading, 3M tape 9876-10 is designated to solve the limitation of existing products.
Typical properties
Resources
Related Products
| Adhesive Type | Acrylic | |||
| Brands | 3M™ | |||
| Conductivity Type | Thermal | |||
| Factory ISO Certification | No ISO Certification information available | |||
| Overall Length (Imperial) | 54.68 yd | |||
| Overall Length (Metric) | 50 m | |||
| Overall Width (Imperial) | 19.69 in | |||
| Overall Width (Metric) | 500 mm | |||
| Product Color | Brown | |||
| Thermal Conductivity (X-Y Axis) | 250 W/m-K | |||
| Thermal Conductivity (Z Axis) | 0.8 W/m-K | |||
| Total Tape Thickness without Liner (Imperial) | 3.9 mil | |||
| Total Tape Thickness without Liner (Metric) | 0.1 mm |
