3M™ DBI-SALA® Standing Seam Roof Anchor 2190073

3M Product Number 21900733M ID 70804491259
  • Installs to flat or sloped standing seam roofs. System clamps to standing seams without special tools, providing an anchorage point for an SRL, including the 3M™ DBI-SALA® Smart Lock Self-Retracting Lifeline.
  • Built-in non-penetrating clamp design with four seam clamps allow for quick attachment without damaging the roof.
  • Slide on the tube legs fit 12,24, 30, 32 and 36 in. seam spacing (30.5, 61, 76.2, 81.3 and 91.4 cm).
  • Portable and Reusable. Anchor can be removed and simply reinstalled in a new location for added jobsite flexibility.
 More...
View all details
For industrial/occupational use only. Not for consumer sale or use.

Specifications
Attribute Name
Value
Anchor Hook Material
Metal
Anchor Install Type
Reusable
Brand
DBI-SALA®
Case Quantity
1 EA
Connected Safety ID Equipped
No
For Use With
3M™ DBI-SALA® Smart Lock Self-Retracting Lifeline (SRL)
Housing Material
Aluminum & Stainless Steel
Housing Type
Aluminum, Stainless Steel
Material
Steel
Mounting Type
Portable & Reusable
Product Color
Black
Product Type
Standing Seam Roof Anchor - For SRL
Recommended Application
Construction
Recommended Industry
Construction
SGBG New Product
Yes
Specifications Met
OSHA 1910.140, OSHA 1926.502
Weight (Imperial)
27.7 lb.
Weight (Metric)
12.6 kg
Weight Capacity
420 lbs. (190 kg)
Weight Capacity (Imperial)
420 lb.
Weight Capacity (Metric)
190.5 kg
Details
  • Installs to flat or sloped standing seam roofs. System clamps to standing seams without special tools, providing an anchorage point for an SRL, including the 3M™ DBI-SALA® Smart Lock Self-Retracting Lifeline.
  • Built-in non-penetrating clamp design with four seam clamps allow for quick attachment without damaging the roof.
  • Slide on the tube legs fit 12,24, 30, 32 and 36 in. seam spacing (30.5, 61, 76.2, 81.3 and 91.4 cm).
  • Portable and Reusable. Anchor can be removed and simply reinstalled in a new location for added jobsite flexibility.
  • Compatible with various fall arrest systems
  • Recommended for use in the construction, general industrial, mining, and oil and gas industries
  • Meets the requirements for  OSHA 1910.140 and OSHA 1926.502
  • This safety equipment is designed for use with additional personal fall protection equipment
  • Compatible with both DBI/SALA Ultra-Lok and Smart Lok SRL lines.

Installs to flat or sloped standing seam roofs. System clamps to standing seams without special tools, providing an anchorage point for an SRL. Built-in non-penetrating clamp design with four seam clamps allow for quick attachment without damaging the roof. Slide on the tube legs fit 12, 24, 30, 32 and 36 in. seam spacing. Portable and Reusable. Anchor can be removed and reinstalled.

Stay on top of projects with 3M™ DBI SALA® roof anchors. Whether your roof is flat or sloped, wood, metal or concrete, there’s a 3M™ DBI SALA® roof anchor to help you get the job done efficiently and securely. They’re easy to install and rugged enough to handle tough environments. Pair these roof anchors with the 3M™ DBI SALA® Smart Lock Leading Edge Self Retracting Lifelines or Ultra Lok Leading Edge Self Retracting Lifelines (Sold Separately) for comfort and productivity with reduced unintentional lockups. Provides freedom of movement around the anchor. Compact and lightweight design features: fast and easy attachment for added productivity. Durable construction stands up to tough work environments. Installs to flat or sloped standing seam roofs. System clamps to standing seams without special tools, providing an anchorage point for an SRL, including the 3M™ DBI SALA® Smart Lock Self Retracting Lifeline. Built in Non penetrating clamp design with four seam clamps allow for quick attachment without damaging the roof. Slide on the Tube legs fit 12, 24, 30, 32 and 36 in. seam spacing (30.5, 61, 76.2, 81.3 and 91.4 cm). Portable and Reusable. Anchor can be removed and simply reinstalled in a new location for added jobsite flexibility.
