- Installs to sloped or flat wood and metal decking roofs. Anchor can be installed to a variety of roofing materials to provide a tie-off point.
- Fast and easy installation. Fastener kit includes 16 ea. ¼-14 x 2-1/2 in. self-tapping screws for steel installation and 8 ea. ¼ x 2-1/2 in. lag screws for wood.
- Secondary D-ring anchor point can be used with horizontal lifeline system and allows user to tie-off to anchor with lanyard or install a 3M™ DBI-SALA® Sayfline™ Horizontal Lifeline between two anchors.
- Portable and reusable. Anchor can be removed and simply reinstalled in a new location for added jobsite flexibility.
|
Attribute Name
|
Value
|
|---|---|
|
Anchor Hook Material
|
Metal
|
|
Anchor Install Type
|
Reusable
|
|
Brand
|
DBI-SALA®
|
|
Case Quantity
|
1 EA
|
|
Connected Safety ID Equipped
|
No
|
|
For Use With
|
3M™ DBI-SALA® Smart Lock Self-Retracting Lifeline (SRL)
|
|
Housing Material
|
Steel Only
|
|
Housing Type
|
Stainless Steel
|
|
Material
|
Steel
|
|
Mounting Type
|
Portable & Reusable
|
|
Overall Length (Imperial)
|
16.5 in
|
|
Product Color
|
Black
|
|
Product Type
|
Swiveling Roof Anchor
|
|
Recommended Application
|
Construction
|
|
Recommended Industry
|
Construction
|
|
SGBG New Product
|
Yes
|
|
Specifications Met
|
OSHA 1910.140, OSHA 1926.502
|
|
Weight (Imperial)
|
14.9 lb.
|
|
Weight (Metric)
|
6.7 kg
|
|
Weight Capacity
|
420 lbs. (190 kg)
|
|
Weight Capacity (Imperial)
|
420 lb.
|
|
Weight Capacity (Metric)
|
190.5 kg
|
- Installs to sloped or flat wood and metal decking roofs. Anchor can be installed to a variety of roofing materials to provide a tie-off point.
- Fast and easy installation. Fastener kit includes 16 ea. ¼-14 x 2-1/2 in. self-tapping screws for steel installation and 8 ea. ¼ x 2-1/2 in. lag screws for wood.
- Secondary D-ring anchor point can be used with horizontal lifeline system and allows user to tie-off to anchor with lanyard or install a 3M™ DBI-SALA® Sayfline™ Horizontal Lifeline between two anchors.
- Portable and reusable. Anchor can be removed and simply reinstalled in a new location for added jobsite flexibility.
- Low-profile design stays out of the way as you work
- Compatible with various fall arrest systems
- Recommended for use in the Construction, General Industrial, Mining, Oil & Gas industries
Installs to sloped or flat wood and metal decking roofs. Anchor can be installed to a variety of roofing materials to provide a tie-off point. Fast and sasy Installation. Secondary D-ring can be used with HLL system and allows user to tie-off to anchor with lanyard or install a 3M™ DBI-SALA®HLL between two anchors. Portable and Reusable. Anchor can be removed and reinstalled.
Stay on top of projects with 3M™ DBI SALA® Roof Anchors. Whether your roof is flat or sloped, wood, metal or concrete, there’s a 3M™ DBI SALA® Roof Anchor to help you get the job done efficiently and securely. They’re easy to install and rugged enough to handle tough environments. Pair these roof anchors with the 3M™ DBI SALA® Smart Lock Self Retracting Lifeline (Sold Separately) for comfort and productivity with reduced unintentional lockups. Compact and Lightweight Design Features: fast and easy attachment for added productivity. Durable Construction Stands up to tough work environments. Installs to Sloped or Flat Wood and Metal Decking Roofs. Anchor can be installed to a variety of roofing materials to provide a tie off point. Fastener kit includes 16 ea. ¼ 14 x 2 1/2 in. self tapping screws for steel installation and 8 ea. ¼ x 2 1/2 in. lag screws for wood. Secondary D ring can be used with horizontal lifeline system and allows user to tie off to anchor with lanyard or install a 3M™ DBI SALA® Sayfline™ Horizontal Lifeline between two anchors. Portable and Reusable. Anchor can be removed and simply reinstalled in a new location for added jobsite flexibility.
For industrial/occupational use only. Not for consumer sale or use.
