- Performs reliably in temperatures as high as 320°F / 160°C
- Commonly used in two-tone painting with high temperature curing cycles
- Prevents bleed-through of paint and solvents
- Readily drapes with scratch-resistant conformability
Our apologies...
An error has occurred while submitting. Please try again later...
Thank you!
Thank you for your interest in 3M packaging, shipping and fulfillment products and solutions. A 3M representative will contact you shortly regarding your inquiry.
|
Attribute Name
|
Value
|
|---|---|
|
Application
|
Paint Masking
|
|
Backing (Carrier) Material
|
Laminated Polymer
|
|
Brand
|
3M™
|
|
Color Family
|
Transparent
|
|
Elongation at Break
|
400 %
|
|
Industries
|
Automotive, Specialty Vehicle, Transportation
|
|
Maximum Operating Temperature (Celsius)
|
160 Degree Celsius
|
|
Maximum Operating Temperature (Fahrenheit)
|
320 Degree Fahrenheit
|
|
Overall Length (Imperial)
|
13.746 ft, 1509.19 ft, 21.817 ft, 3.674 ft
|
|
Overall Length (Metric)
|
1.12 m, 4.19 m, 460 m, 6.65 m
|
|
Overall Thickness (Imperial)
|
1.2 mil
|
|
Overall Thickness (Metric)
|
0.03 mm
|
|
Overall Width (Imperial)
|
1.167 ft, 1.67 ft, 14.763 ft, 19.914 ft
|
|
Overall Width (Metric)
|
0.356 m, 0.51 m, 4.5 m, 6.07 m
|
|
Product Color
|
Transparent
|
|
Shelf Life in Months (From Date of Manufacture)
|
18
|
|
Size (Imperial)
|
13.746 ft x 19.914 ft x 1.2 mil, 1509.19 ft x 1.167 ft x 1.2 mil, 21.817 ft x 14.763 ft x 1.2 mil, 3.674 ft x 1.67 ft x 1.2 mil, 1.167 ft x 1509.19 ft, 1.67 ft x 3.674 ft, 14.763 ft x 21.817 ft, 19.914 ft x 13.746 ft
|
|
Size (Metric)
|
1.12 m x 0.51 m x 0.03 mm, 4.19 m x 6.07 m x 0.03 mm, 460 m x 0.356 m x 0.03 mm, 6.65 m x 4.5 m x 0.03 mm, 0.356 m x 460 m, 0.51 m x 1.12 m, 4.5 m x 6.65 m, 6.07 m x 4.19 m
|
|
Tensile Strength (Imperial)
|
5.6 lb/in
|
|
Tensile Strength (Metric)
|
10 N/cm
|
- Performs reliably in temperatures as high as 320°F / 160°C
- Commonly used in two-tone painting with high temperature curing cycles
- Prevents bleed-through of paint and solvents
- Readily drapes with scratch-resistant conformability
- Can be converted with 3M™ Masking Tape to make pre-masked rolls of film
- Available as rolls, pre-cut sheets on a roll, or covers
3M™ High Temperature Paint Masking Film 7302 is a high-performance masking film designed to protect surfaces from paints with cure cycles of up to 320°F / 160°C. This film drapes readily, conforms to surfaces and prevents bleed-through and surface contamination. It is commonly used for two-tone automotive painting that requires high temperature curing.
Higher Efficiency in Paint Masking
3M™ High Temperature Paint Masking Film 7302 is a high performance, high temperature masking film that provides excellent conformability as well as preventing bleed-through and fiber contamination. It is designed to resist temperatures as high as 320°F / 160°C for 45 minutes, making it suitable for effective paint masking during paint booth cycles. The soft flexing design makes it easy to wrap contoured and curved surfaces, with good draping qualities for sufficient coverage. It is soft enough to resist scratching of clear coat and other protective layers. Its surface is engineered to resist bleed-through of solvents, enamels, lacquers and paint. The film surface is modified to allow for good paint adhesion and inhibits paint flaking.
Recommended Applications
- Two-tone paint masking for automobiles, airplanes, trucks, buses, and boats
- Automotive fascia paint masking
- Automotive paint repair
Clean Masking System
3M™ High Temperature Paint Masking Film 7302 is compatible with automotive paints and inhibits paint flaking. This masking film is ideal where contamination-free painting is required and is excellent for two-tone and blackout applications. It readily accepts 3M masking tapes to be easily applied to the vehicle, and both tape and film can be smoothly dispensed together using a 3M apron taper.
