3M™ Cushion-Mount™ Plus Plate Mounting Tape L1120

3M Product Number L1120
Products
  • Tan, flexo plate mounting tape has the air release feature and an adhesive that is tolerant of ink contaminants, allowing for easy and clean plate removal
  • This 0.020 inch (0.51 mm) double coated foam tape has the air release feature with a plate side adhesive technology designed to remove with less force in the presence of ink contaminants on flexographic print plates
  • Provides high quality process print. The adhesives remove cleanly from the print plate and print cylinder
  • Flexographic printing, flexographic printers
 More...
View all details
For industrial/occupational use only. Not for consumer sale or use.
Overall Length (Imperial)
Overall_Length_Imperial
Overall Length (Metric)
Overall_Length_Metric
Overall Width (Imperial)
Overall_Width_Imperial
Overall Width (Metric)
Overall_Width_Metric
Products Available
Available options:
 Overall Length (Imperial), Overall Length (Metric), Overall Width (Imperial) and Overall Width (Metric)
All Options
  • Product Form
    Overall Length (Imperial)
    Overall Length (Metric)
    Overall Width (Imperial)
    Overall Width (Metric)
    Product Color
  • 3M™ Cushion-Mount™ Plus Plate Mounting Tape L1120, Tan, 18 in x 25 yd, 1 roll per case
    Product Form
    Roll
    Overall Length (Imperial)
    25 yd
    Overall Length (Metric)
    22.86 m
    Overall Width (Imperial)
    18 in
    Overall Width (Metric)
    457 mm
    Product Color
    Tan
  • 3M™ Cushion-Mount™ Plus Plate Mounting Tape L1120, Tan, 54 in x 25 yd, 1 roll per case
    Product Form
    Roll
    Overall Length (Imperial)
    25 yd
    Overall Length (Metric)
    22.86 m
    Overall Width (Imperial)
    54 in
    Overall Width (Metric)
    1371.6 mm
    Product Color
    Tan
  • 3M™ Cushion-Mount™ Plus Plate Mounting Tape L1120, Tan, 20 mil, Roll, Config
    Product Form
    Roll
    Product Color
    Tan
Close
Where To Buy
Details
  • Tan, flexo plate mounting tape has the air release feature and an adhesive that is tolerant of ink contaminants, allowing for easy and clean plate removal
  • This 0.020 inch (0.51 mm) double coated foam tape has the air release feature with a plate side adhesive technology designed to remove with less force in the presence of ink contaminants on flexographic print plates
  • Provides high quality process print. The adhesives remove cleanly from the print plate and print cylinder
  • Flexographic printing, flexographic printers
  • Cushioned flexographic plate mounting sticky back foam tape

Our 3M™ Cushion-Mount™ Plus Plate Mounting Tape L1120 with easy mount adhesive is designed for mounting flexographic print plates to cylinders or sleeves. This tan foam plate mounting tape provides high quality process print.

Bubble Free Flexographic Plate Mounting
3M™ Cushion-Mount™ Plus Plate Mounting Tape L1120 is a tan foam tape that provides high quality process print. It has the air release feature that allows for bubble free mounting. Notably, this flexographic plate mounting tape has excellent resistance to lifting on press and is tolerant of ink contaminants, allowing for easy and clean plate removal.

Recommended Applications

  • Mounting photopolymer plates to flexographic printing cylinders and sleeves
  • Used in process printing processes
  • 3M sticky back tapes are designed for wide-web presses to print film or paper for flexible packaging industry

This cushion tape is manufactured for 20 mil applications. It is constructed with engineered acrylic adhesives. The adhesive on the linered (plate) side of the tape is designed for mounting photopolymer plates. Easy plate removal from tape may result in less worker fatigue and plate damage. The adhesive on the non-linered (sleeve/cylinder) side is designed for mounting to flexographic printing cylinders or sleeves, providing easy application at mounting and clean removal when demounting.

On Easy with Reduced Air Entrapment
3M air release liners have a crosshatched pattern, unlike other mounting tapes that use a pebbled or flat release liner. The embossed crosshatched pattern imprints unique micro-channels into the easy mount adhesive that allows entrapped air to escape. Air bubbles disappear from between the tape and plate, and between the tape and sleeve or cylinder for virtually bubble-free mounting. Setup is faster with smoother surfaces for cleaner print quality and higher productivity. The adhesive maintains tight contact with reduced edge lifting.

Keep the Presses Running and your Customers Coming Back
For decades, 3M products have been at work in printing plants helping to improve the quality of the work that goes out and the efficiency of how it gets done.
