- Natural, 5 mil (0.13 mm) adhesive transfer tape on a 60# glassine paper liner
- Quick stick adhesion and immediate bond
- Exceptional adhesion properties and bonds well to high and low surface energy plastics
- Good solvent and moisture resistance
For industrial/occupational use only. Not for consumer sale or use.
Overall Length (Imperial)
Overall_Length_Imperial
Overall Width (Imperial)
Overall_Width_Imperial
5 Products Available
Available options:
Overall Length (Imperial) and Overall Width (Imperial)
Specifications
|
Attribute Name
|
Value
|
|---|---|
|
Adhesive Type
|
Acrylic
|
|
Alternative Sale Availability
|
6. This item is for industrial use only and there are no VOC restrictions.
|
|
Automotive OEM Specification
|
Ford WSS-M11P62, GM 9985281
|
|
Brand
|
3M™
|
|
Color Family
|
Transparent
|
|
Industries
|
Aerospace, Automotive, Converter Solutions, Electronics, General Industrial, Medical, Specialty Vehicle, Transportation, Woodworking
|
|
Maximum Operating Temperature (Celsius)
|
93 Degree Celsius
|
|
Maximum Operating Temperature (Fahrenheit)
|
200 Degree Fahrenheit
|
|
Minimum Operating Temperature (Celsius)
|
-40 Degree Celsius
|
|
Minimum Operating Temperature (Fahrenheit)
|
-40 Degree Fahrenheit
|
|
Overall Length (Imperial)
|
10 yd, 60 yd, 60.15 yd
|
|
Overall Length (Metric)
|
54.86 m, 55 m, 9.14 m
|
|
Overall Width (Imperial)
|
1 in, 27 in, 4 in, 54 in
|
|
Overall Width (Metric)
|
101.6 mm, 1371.6 mm, 25.4 mm, 685.8 mm
|
|
Primary Liner
|
60# Glassine Paper
|
|
Primary Liner Color
|
Tan
|
|
Primary Liner Thickness (Imperial)
|
3.2, 3.2 mil
|
|
Primary Liner Thickness (Metric)
|
0.08 mm
|
|
Size (Imperial)
|
1 in x 60 yd, 27 in x 60.15 yd, 4 in x 10 yd, 54 in x 60 yd
|
|
Size (Metric)
|
101.6 mm x 9.14 m, 1371.6 mm x 55 m, 25.4 mm x 54.86 m, 685.8 mm x 55 m
|
|
Substrate 1
|
Foam (EPDM - EVA - Neoprene - Nitrile Sponge Blend - Polyurethane, Ester), Foam (Melamine), Foam (Polyimide), Foam (Polyurethane, Ether), Foam (PVC), Glass (Inked Glass - Ceramic), Metal (Aluminum - Powder Coated - Copper - Stainless Steel - Zinc/Galvanized), Plastics/Composites (ABS - Carbon Fiber - Acrylic - Fiberglass - Polycarbonate - Polyester - Polyimide - Polystyrene - Rigid Vinyl), Plastics/Composites (Glass Filled Nylon), Plastics/Composites (Nylon - PEEK - Polyethylene - Polypropylene)
|
|
Substrate 2
|
Foam (EPDM - EVA - Neoprene - Nitrile Sponge Blend - Polyurethane, Ester), Foam (Melamine), Foam (Polyimide), Foam (Polyurethane, Ether), Foam (PVC), Glass (Inked Glass - Ceramic), Metal (Aluminum - Powder Coated - Copper - Stainless Steel - Zinc/Galvanized), Plastics/Composites (ABS - Carbon Fiber - Acrylic - Fiberglass - Polycarbonate - Polyester - Polyimide - Polystyrene - Rigid Vinyl), Plastics/Composites (Glass Filled Nylon), Plastics/Composites (Nylon - PEEK - Polyethylene - Polypropylene)
|
|
TDS Required
|
Yes
|
|
Total Tape Thickness without Liner (Imperial)
|
5 mil
|
|
Total Tape Thickness without Liner (Metric)
|
0.127 mm
|
|
Units per Case
|
1 Roll, 36 Roll
|
Details
- Natural, 5 mil (0.13 mm) adhesive transfer tape on a 60# glassine paper liner
- Quick stick adhesion and immediate bond
- Exceptional adhesion properties and bonds well to high and low surface energy plastics
- Good solvent and moisture resistance
- Laminating adhesive format provides good conformability to irregular surfaces
3M™ Adhesive Transfer Tape 9627 immediately bonds to high and low surface energy materials. The 60# glassine paper liner provides dimensional stability and improved handling with ease in die cutting and laminating applications.
3M™ Adhesive Transfer Tape 9627 offers high bond strength on a variety of materials, including hard-to-stick-to polypropylene and powder-coated paints
Engineered for quick and strong adhesion, 3M™ Adhesive Transfer Tape 9627 offers high bond strength on a variety of materials, including hard-to-stick-to polypropylene and powder-coated paints. Designed with just 5 mil (0.13 mm) of 3M™ Quick Bonding Adhesive 360, it provides exceptional strength with minimal adhesive, delivering a strong, yet light and smooth application and thin bond lines. The tape is resistant to humidity, UV, water, short term temperatures up to 250°F (121°C) and chemicals (including oil, mild acids, and alkalis).
Recommended Applications
- Plastic housing and component assembly (bezel bonding)
- Interior decorative trim attachment
3M™ Adhesive Transfer Tape 9627 features 3M™ Quick Bonding Adhesive 360 which provides high bond strength with low odor. The noted advantages of 360 adhesive are its extremely high peel adhesion and equally high adhesion on both polypropylene and steel substrates. It offers more bond strength with less adhesive as well as quick stick to many low surface energy substrates.
Understanding Adhesive Transfer Tapes
Adhesive transfer tapes are rolls of pressure sensitive adhesive pre-applied to a special release liner. For application, the tape is simply pressed, adhesive side down, to a surface and the liner is peeled off. A variety of adhesive properties and liners are available to meet requirements for applications such as nameplate attachment to high and low surface energy plastics, appliance graphic overlays that perform in high temperatures, foam gasketing, web splicing, signs, posters, banners, point-of-purchase displays, and more.
Get Data for Finite Element Analysis
Pressure Sensitive Adhesive properties are frequency and temperature sensitive. 3M has developed Material Data Cards (MDCs) for common 3M PSAs for use with many commercially available FEA software applications. Learn more.
