  6. 3M™ Scotchlok™ Male Disconnect Non-Insulated, 50/bottle, MU10-250DMX, allows for quick and easy disconnect of wires, 500/Case

3M™ Scotchlok™ Male Disconnect Non-Insulated, 50/bottle, MU10-250DMX, allows for quick and easy disconnect of wires, 500/Case

Part Number MU10-250DMX3M ID 80611458367UPC 00051128586914
  • Non-insulated, butted-seam barrel with a beveled mouth offers easy insertion of wires
  • This male disconnect terminal offers excellent holding force
  • Allows for quick and easy disconnect of wires
  • Accommodates wire sizes 16 to 14 AWG
 More...
View all details
View Legal Disclaimer
For industrial/occupational use only. Not for consumer sale or use.
Specifications
Attribute Name
Value
Barrel Style
Butted
Brand
Scotchlok™
Connection Width (Imperial)
0.25 in
Connection Width (Metric)
6.35 mm
Disconnect Type
Male
Fastener Orientation
Male
Insulation Material
Non-Insulated
Male Tab Width (W')
0.250 Inch
Manufacturing Origin
USA
Maximum Conductor Size (Imperial)
10 AWG
Minimum Conductor Size (Imperial)
12 AWG
Minimum Order Quantity
50
Overall Length (Imperial)
0.75 in
Packaging
50 per bottle
Pad Width
0.25 in
Solution for
Wireless Network: Infrastructure Accessories
Tab Width
0.250
Terminal Style
Standard
Terminal Type
Standard
Units per Case
500
Details
  • Non-insulated, butted-seam barrel with a beveled mouth offers easy insertion of wires
  • This male disconnect terminal offers excellent holding force
  • Allows for quick and easy disconnect of wires
  • Accommodates wire sizes 16 to 14 AWG
  • Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating

3M™ Scotchlok™ Non-Insulated Butted Seam Male Disconnect terminal offers superior holding force while allowing for quick and easy disconnect. The terminal has a non-insulated, butted-seam barrel and withstands a maximum temperature of 347 degrees F (175 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

3M™ Scotchlok™ Non-Insulated Butted Seam Male Disconnect terminal attaches to the mating part with a tongue that slips over the female tab. It has a non-insulated, butted-seam barrel and a beveled mouth to easily guide the wire into position. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
