3M™ Scotchkote™ Epoxy Coating 323i

  • 3M ID 80630001800
  • UPC 50051135329547,051135329542

Get excellent corrosion protection for steel pipes and metal substrates

Excellent adhesion

High build, up to 45 mils, in one application

View more details



  • Get excellent corrosion protection for steel pipes and metal substrates
  • Excellent adhesion
  • High build, up to 45 mils, in one application
  • Can be applied to a substrate as cold as 41°F/5°C
  • Resistant to damage from acids and bases in pH range 2-14
  • Resistant to hydrocarbons such as crude oil, motor oils and gasoline
  • Applicable by cartridge, brush, roller, HSS or plural component spray
  • 2A:1B Volumetric Mix Ratio

3M™ Scotchkote™ Liquid Epoxy Coating 323/323i is a two part system designed to protect steel pipe and other metal substrates from the harsh affects of corrosion.

Provide excellent corrosion protection to steel pipes and metal substrates, with 3M™ Scotchkote™ Pipe Coating 323. Our two-part system can be used as a joint coating, refurbishing coating or pipe coating. The cured coating withstands pigging operations in use, for significant benefits to product pumping costs. It can be applied by hand, using a brush or roller. General application steps when using our product: 1. Remove oil, grease, and loosely adhering deposits 2. Verify the air temperature is 3°C above the dew point 3. Abrasive blast clean surface to NACE #2/SSPC-SP10, ISO 8501:1 SA-2 1/2 near white metal 4. With air hose, clean blasted surface of any abraded debris then verify anchor profile is 2-4 mils/50-100 microns 5. With the substrate between 5°C and 93°C dew point 3°C below air temperature, apply Scotchkote™ Liquid Epoxy Coating 323/323i at minimum film of 25 mil/ 625 microns 6. Apply Scotchkote™ 323/323i as soon as possible after blasting but no more than 4 hours 7. Allow to cure per time and temperature chart provided 8. Visually or electrically inspect the coating for defects 9. Repair all defects using Scotchkote™ 323/323i as repair material Our pipe coating system comprising of: 3M™ Scotchkote™ 323, 450 ml, Application Gun (1 each) 90 Degree Spray Nozzle (24/box) 450 ml Mix Nozzles (24/box) Straight Spray Nozzle (24/box) Liquid Epoxy Coating Cartridges, 323i, 50ml Mixing Nozzle for 50ml Cartridge of 323i Application Gun, manual for 323i
